| Highlight: | 2 finger pneumatic gripper long stroke,pneumatic gripper two jaw parallel,TPL long stroke gripper |
||
|---|---|---|---|
Excellent performance
1. The TPL grippers have super long stroke and 4 pistons structure.
â— Longer stroke to meet the requirements of special working conditions
â— Unique four-piston structure, smaller volume, higher gripping force
Model and Technical Parameters
|
Model |
Stroke per jaw [mm] |
Closing/ opening force[N] |
Weight [kg] |
Recommended workpiece weight[kg] |
Closing/ opening time[s] |
Repeat accuracy [mm] |
Protection class IP |
| TPL-40A | 40 | 1790/1050 | 4.5 | 8.95 | 0.40/0.40 | 0.02 | 40 |
| TPL-70A | 70 | 4450/2940 | 9.1 | 22.25 | 0.70/0.70 | 0.02 | 40 |
Hot Tags: 2 finger pneumatic gripper, long stroke tpl, China, suppliers, manufacturers, factory, custom, price, design, long stroke pneumatic gripper, two jaw parallel pneumatic gripper, heavy duty pneumatic gripper, 2 Finger robot Gripper, 2 Jaw gripper, 2 jaw air grippers
