Product Details:
|
| Model: | TPL-40A | Stroke Per Jaw [mm]: | 40 |
|---|---|---|---|
| Closing/ Opening Force[N]: | 1790/1050 | Weight [kg]: | 4.5 |
| Recommended Workpiece Weight[kg]: | 8.95 | Closing/ Opening Time[s]: | 0.40/0.40 |
| Repeat Accuracy [mm]: | 0.02 | Protection Class IP: | 40 |
| Model: | TPL-70A | Stroke Per Jaw [mm]: | 70 |
| Closing/ Opening Force[N]: | 4450/2940 | Weight [kg]: | 9.1 |
| Recommended Workpiece Weight[kg]: | 22.25 | Closing/ Opening Time[s]: | 0.70/0.70 |
This pneumatic gripper features a longer stroke, making it suitable for specialized working conditions. Its unique four-piston structure provides a smaller volume and higher gripping force.
Target Industries: Automation, Robotics, Manufacturing, Assembly Lines
Typical Applications: Pick and place, machine tending, part handling
| Parameter | Value |
|---|---|
| Stroke per jaw [mm] | 40 |
| Closing/ opening force[N] | 1790/1050 |
| Weight [kg] | 4.5 |
| Recommended workpiece weight[kg] | 8.95 |
| Closing/ opening time[s] | 0.40/0.40 |
| Repeat accuracy [mm] | 0.02 |
| Protection class IP | 40 |
| Parameter | Value |
|---|---|
| Stroke per jaw [mm] | 70 |
| Closing/ opening force[N] | 4450/2940 |
| Weight [kg] | 9.1 |
| Recommended workpiece weight[kg] | 22.25 |
| Closing/ opening time[s] | 0.70/0.70 |
| Repeat accuracy [mm] | 0.02 |
| Protection class IP | 40 |
