| Model: | TWL-63-75 | Stroke Per Jaw [mm]: | 75 |
|---|---|---|---|
| Closing/ Opening Force[N]: | 3100/2790 | Weight [kg]: | 12.6 |
| Closing/ Opening Time[s]: | 0.28/0.28 | Allowable Moments Mx[Nm]: | 880 |
| Allowable Moments My/Mz[Nm]: | 720 | Allowable Forces Fa[N]: | 15500 |
| Repeat Accuracy [mm]: | 0.05 | Protect Ion Class IP: | 64 |
| Model: | TWL-63-100 | Stroke Per Jaw [mm]: | 100 |
| Weight [kg]: | 15 | Closing/ Opening Time[s]: | 0.36/0.36 |
| Allowable Moments Mx[Nm]: | 980 | Allowable Moments My/Mz[Nm]: | 820 |
| Model: | TWL-63-125 | Stroke Per Jaw [mm]: | 125 |
| Weight [kg]: | 17.7 | Closing/ Opening Time[s]: | 0.42/0.42 |
| Model: | TWL-63-175 | Stroke Per Jaw [mm]: | 175 |
| Weight [kg]: | 22.3 | Closing/ Opening Time[s]: | 0.57/0.57 |
This 2-finger pneumatic parallel gripper is designed for reliable and efficient handling of small parts. The body is constructed from high-strength aluminum alloy, making it both lightweight and robust. With a focus on price-performance, this gripper offers exceptional value for a variety of applications.
Ideal for: Automation, Robotics, Pick and Place Systems, Assembly Lines.
| Model | Stroke per jaw [mm] | Closing/ opening force[N] | Weight [kg] |
|---|---|---|---|
| TWL-63-75 | 75 | 3100/2790 | 12.6 |
| TWL-63-100 | 100 | 3100/2790 | 15 |
| TWL-63-125 | 125 | 3100/2790 | 17.7 |
| TWL-63-175 | 175 | 3100/2790 | 22.3 |
